FORK SENSOR

Price 5300.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Number

FORK SENSOR Specification

Ingress Protection
III

Power Consumption
20 mA Ampere

Cable Length
42 Millimeter (mm)

Application
Cutting of continuous labels without print marks

Sensitivity
, light/dark switching

Sensor Type
WFS3-40N415

Signal Type
Digital

Features
Optical detection principle

Housing Material
PA (glass-fiber reinforced)

Wireless
Yes

IP Rating
IP65

Operating Temperature
20 C ... +60 C Celsius (oC)

Response Time
1 Days

Product Type
WFS3-40N415

Power Rating
IP65

Input
U > 5 V ... < UV

Output
NPN

Function
Optical detection principle

Usage
labels without print marks

Accuracy
42 mm mm

Resolution
integrated solutions in industrial automation.

Voltage
10 V DC ... 30 V DC Volt (v)

Weight
36 g Grams (g)

Rated Voltage
10 V DC ... 30 V DC Volt (V)

Usage & Applications
Cutting of continuous labels without print marks

Warranty
1 year

Cable Type
light/dark switching

Display Type
WFS3-40N415

Rated Current
100 mA Milliampere (mA)

Frequency
10 kHz Kilohertz ( KHZ )

Material
PA (glass-fiber reinforced)

FORK SENSOR Trade Information

Minimum Order Quantity
1 Number

Delivery Time
1 Week

About FORK SENSOR

PRODUCT DISCRIPTION

The slim, forked shape of the WFS has been specially developed for the requirements of the labeling process. The design allows the sensor to be mounted directly on the edge of a label dispenser. Difficulty in detecting the label gap is finally eliminated the sensor's switching threshold can be taught-in while the label strip is running. This sophisticated operating concept means the sensor can be adjusted to different labels quickly, easily, and reliably. The fast response time guarantees exceptional repeat accuracy.

AT A GLANCE

Housing with slim forked shape.
Simple and precise setting of the switching threshold via IO-Link, teach-in button, or plus/minus buttons.
Light/dark switching function.
Fast response time: 50 s.
PNP or NPN switching output.
Plastic housing with IP 65 enclosure rating.
Smart sensor with integrated IO-Link interface

YOUR BENEFITS

Flexible and simple mounting directly on the edge of a label dispenser ensures a high level of accuracy in the process.
Small housing allows simple installation even where space is limited.
User-friendly adjustment allows easy and quick commissioning.
Fast response times enable precise detection even at very high track speeds.
Thanks to IO-Link or external teach-in, the switching threshold can be adapted while the process is running, increasing process reliability.
Easy to access data from the PLC via IO-Link
