G10 PHOTOELECTRIC SENSOR

Name: G10 PHOTOELECTRIC SENSOR
Brand: JAY KAY ENTERPRISES
Price: 3100.0 INR
Availability: InStock

Price 3100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G10 PHOTOELECTRIC SENSOR Specification

Mounting Type
hole, 4.2 mm

Spectral Range
0 m ... 40 m

Features
Through-beam photoelectric sensor

Application
Monitoring access barriers

Wireless
Yes

Sensor Type
GSE10-P4111

Response Time
1 Days

Power Consumption
15 mA Ampere

Housing Material
Plastic, ABS/PMMA

Operating Temperature
30 C ... +60 C Celsius (oC)

Measurement Range
0 m ... 35 m

Ingress Protection
A 5) B 6) C 7) D 8)

IP Rating
IP67

Mounting Thread
hole, 4.2 mm

Signal Type
Digital

Product Type
GSE10-P4111

Power Rating
IP67

Input
PHOTOELECTRIC SENSORS

Output
PNP

Function
Through-beam photoelectric sensor

Usage
Monitoring access barriers

Accuracy
180 mm mm

Resolution
industrial automation

Voltage
10 V DC ... 30 V DC Volt (v)

Usage & Applications
Monitoring access barriers

Rated Voltage
10 V DC ... 30 V DC Volt (V)

Weight
70 Grams (g)

Cable Type
Male connector M12, 4-pin

Warranty
1 year

Display Type
PHOTOELECTRIC SENSORS

Conductor
4-pin

Material
plastic

Frequency
1,000 Hz Hertz (HZ)

Rated Current
100 mA Milliampere (mA)

G10 PHOTOELECTRIC SENSOR Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About G10 PHOTOELECTRIC SENSOR

PRODUCT DESCRIPTION

The G10 product family is characterized by optimum detection performance wherever space is at a premium. It supports numerous different options for optics, electronics, principles of operation, power supplies, and switching outputs. Combined with an extensive range of accessories, these sensors are able to support a wide variety of applications. The patented Q-Lock assembly system for the G10 reduces the time required to install and align the sensor with an assembly rod to just a few seconds, making this the ide al product for logistics applications. Summary: The G10 product family provides quick and flexible sensor installation, ensures error-free operation, and keeps costs under control.

AT A GLANCE

Long sensing ranges: 1,200 mm with background suppression; 15 m on PL80A reflector.
Pinpoint LED with bright and precise light spot.
Small housing design.
10 30 VDC or 24 240 VAC/VDC power supply with PNP/NPN or relay output.
Rugged sensor housing with metal-reinforced holes for assembly.
Q-Lock assembly system for mounting the sensor within a few seconds.

YOUR BENEFITS

Long sensing ranges for maximum operating reserves.
Efficient installation: The G10 and the Q-Lock assembly system save valuable hours when mounting and commissioning multiple sensors.
A single sensor family for all industrial and commercial fields of application.
Universal DC or AC/DC power supply for even greater application flexibility.
Highly reliable and durable despite optical interference or mechanical loads.
Wide range of accessories simplifies sensor integration: aids for assembly, connecting cables, and reflectors.

FIELDS OF APPLICATION

Logistics: Storage & Conveyor, especially pallet detection.
Machine builders (e.g. packaging, handling, wood processing, paper).
Automotive.
Automated car park systems.
Doors and gates.
Distribution.

ORDERING INFORMATION

Other models and accessories www.sick.com/G10.
Functional principle: Photoelectric proximity sensor.
Functional principal detail: Background suppression.
Light source: LED.
Voltage type: DC.
Switching mode: Light/dark switching.
Type of light: Infrared light.

Advanced Through-Beam Detection

Employing sophisticated through-beam photoelectric technology, the G10 sensor delivers precise access monitoring across industrial environments. Its high detection accuracy and extended spectral range provide dependable operation even in challenging conditions, ensuring barriers are constantly supervised.

Rugged and Versatile Design

Built with robust ABS/PMMA plastic and an IP67 rating, this sensor withstands exposure to dust and moisture. Versatile mounting options and standardized connectors simplify integration, making it suitable for new installations or system upgrades.

FAQ's of G10 PHOTOELECTRIC SENSOR:

Q: How does the G10 Photoelectric Sensor operate in monitoring access barriers?

A: The G10 uses a through-beam detection method, sending and receiving photoelectric signals over distances up to 35 meters. When an object interrupts the beam, the digital output signals the presence, making it ideal for access barrier monitoring.

Q: What are the benefits of the wireless functionality in this photoelectric sensor?

A: Wireless capability allows for clean and flexible installation, reducing wiring complexity while enhancing system scalability and minimizing maintenance disruptions.

Q: Where can the G10 Photoelectric Sensor be installed?

A: Due to its IP67 rating and compact plastic housing, the sensor is suitable for both indoor and outdoor environments, including industrial sites, warehouses, and areas where reliable barrier monitoring is essential.

Q: What is the typical process for mounting the G10 sensor?

A: The sensor features a 4.2 mm mounting hole, allowing easy attachment to various surfaces or support structures using standard hardware, which accelerates installation and ensures secure placement.

Q: How does the sensor maintain accuracy and reliability over its operational range?

A: With a 0-35 meter range and 180 mm accuracy, the sensor utilizes high-frequency (1,000 Hz) photoelectric technology that performs consistently even in environments with variable lighting or contamination.

Q: When is maintenance or replacement generally required for this sensor?

A: Designed for durability, routine maintenance involves checking alignment and connector integrity. With a one-year warranty, the sensor can be replaced if defects or significant performance drop occurs within the coverage period.

Q: What are the main application benefits for industrial automation?

A: The sensor's precise detection, robust build, and digital output make it perfectly suited for automation tasks-improving safety, process control, and operational efficiency in industries that require strict monitoring of personnel and vehicle access.
