G6 Reflective Photoelectric Sensor

Name: G6 Reflective Photoelectric Sensor
Brand: JAY KAY ENTERPRISES
Price: 2350.0 INR
Availability: InStock

Price 2350.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G6 Reflective Photoelectric Sensor Specification

Mounting Thread
holes M3

Application
Leading edge detection and presence checking

Power Consumption
30 mA Ampere

Sensor Type
GTB6-N1212

Operating Temperature
25 C ... +55 C Celsius (oC)

Measurement Range
35 mm ... 140 mm

Spectral Range
5 mm ... 250 mm

Ingress Protection
A 7) B 8) D 9

IP Rating
IP67

Sensitivity
potentiometer

Response Time
1 Days

Features
Photoelectric proximity sensor

Signal Type
Digital

Cable Length
2 Meter (m)

Wireless
No

Mounting Type
holes M3

Housing Material
Plastic, ABS/PC

Power Rating
IP67

Product Type
GTB6-N1212

Input
PHOTOELECTRIC SENSORS - GTB6-N1212

Output
NPN

Function
Photoelectric proximity sensor

Usage
Leading edge detection and presence checking

Accuracy
6 mm mm

Resolution
industrial automation

Voltage
10 V DC ... 30 V DC Volt (v)

Rated Voltage
10 V DC ... 30 V DC Volt (V)

Weight
60 Grams (g)

Usage & Applications
Leading edge detection and presence checking

Cable Type
Cable, 3-wire, 2 m

Warranty
1 year

Display Type
PHOTOELECTRIC SENSORS - GTB6-N1212

Rated Current
30 mA Milliampere (mA)

Conductor
0.14 mm

Material
Plastic, PMMA

Frequency
1,000 Hertz (HZ)

G6 Reflective Photoelectric Sensor Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About G6 Reflective Photoelectric Sensor

PRODUCT DESCRIPTION

The photoelectric sensors in the G6 product family with their miniature housings will impress you across the board with both their standard mounting configuration of 1-inch spaced holes and also their functional characteristics. The variants with a stainless steel 1.4404 (316L) housing are especially resistant to chemicals and cleaning agents in washdown applications. With Pinpoint LED and laser technology, metal inserts for mounting, large and bright indicator LEDs, user-friendly adjustment screws, IP67 and IP69K enclosure ratings, as well as the very latest ASIC technology from SICK, the G6 series far exceeds the current standard.

AT A GLANCE

Pinpoint LED and class 1 laser variants.
SICK ASIC, the result of decades of experience with photoelectric sensors.
Photoelectric proximity sensors with background suppression, energetic photoelectric proximity sensors, and through-beam photoelectric sensors.
ABS plastic housing and V4A stainless-steel 1.4404 (316L) housing.
Enclosure ratings IP67 and IP69K.

YOUR BENEFITS

Pinpoint LEDs (with visible red light and infrared light) or variants with a laser light spot enable objects to be detected reliably and are therefore suitable for a broad range of applications.
Superior optical performance and robustness thanks to the ASIC from SICK.
Quick and easy mounting and high durability thanks to the metal inserts with M3 thread.
Easy installation and adjustment with user friendly potentiometer and highly visible indicator LEDs.
Variants with a stainless-steel housing and IP69K enclosure rating ensure a long sensor service life in demanding washdown ap plications

FIELDS OF APPLICATION

Industries with high cleaning requirements (e.g. food and beverage).
Harsh environments requiring tough metal housing. e.g. due to mechanical impacts.
Applications with high aesthetic standards

ORDERING INFORMATION

Other models and accessories www.sick.com/G6.
Sensing range min. / max.: 10 mm / 300 mm.
Functional principle: Photoelectric proximity sensor.
Functional principal detail: Energetic.
Switching mode: Light/dark switching.
Switching output: NPN

Rugged, Reliable Detection

The G6 Reflective Photoelectric Sensor is engineered for environments demanding high ingress protection and accurate operation. With an IP67 rating, it resists dust and water ingress, making it perfect for challenging industrial settings. Its robust housing of plastic ABS/PC ensures durability while maintaining a light weight for effortless integration.

Adaptable to Various Applications

From leading edge detection to presence checking, the GTB6-N1212 sensor delivers exceptional performance. Its adjustable sensitivity and quick response make it suitable for automated inspection, packaging, or assembly lines, enhancing production accuracy and efficiency with minimal maintenance required.

Easy Integration and Operation

Installation is simplified with M3 mounting holes and a 2-meter cable. The sensor operates on 10 V DC to 30 V DC and supports NPN digital output, making it compatible with most industrial control systems. Its simple interface and user-friendly design reduce setup time and facilitate continuous, stable operation.

FAQ's of G6 Reflective Photoelectric Sensor:

Q: How does the G6 Reflective Photoelectric Sensor work in industrial environments?

A: This sensor emits a beam of light and detects its reflection from a target object. When the light beam is interrupted or reflected by an object within its 35 mm to 140 mm range, the sensor signals a presence or leading edge, making it suitable for automation tasks.

Q: What benefits does the IP67 rating provide for this photoelectric sensor?

A: An IP67 rating ensures that the sensor is dust-tight and protected against temporary immersion in water. This increases reliability in dusty or wet industrial environments and reduces the risk of downtime caused by environmental factors.

Q: When should I use the GTB6-N1212 photoelectric proximity sensor?

A: The sensor is ideal for applications that require fast and accurate detection of objects, such as presence checking, counting, and leading edge detection on conveyor belts, packaging machines, or automated inspection systems.

Q: Where can the G6 Reflective Sensor be installed?

A: It can be mounted using M3 threaded holes on equipment in industrial automation lines, including packaging, assembly, and conveyor systems. Its compact size and flexible cable allow installation in tight or challenging spaces.

Q: What process is needed to set up the sensor's sensitivity?

A: Sensitivity can be adjusted via the built-in potentiometer. Simply turn the potentiometer while observing the sensor's output to calibrate detection distance for your specific application.

Q: How does the sensor output its signal, and what type of control systems is it compatible with?

A: The GTB6-N1212 outputs a digital NPN signal, making it suitable for direct integration with PLCs and most industrial automation controllers.

Q: What is the warranty and typical lifespan of the G6 sensor?

A: The sensor comes with a 1-year manufacturer's warranty. Its robust construction and reliable components provide long operational life in standard industrial conditions when used within specified ratings.
