LASER DISTANCE SENSOR: DX50

Price 21900.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Number

LASER DISTANCE SENSOR: DX50 Specification

Power Consumption
1.85 W 2) Watt (W)

Features
200 mm ... 10,000 mm, 90% remission factor

Housing Material
Metal (zinc diecast)

Application
Determining the roll diameter

Signal Type
Digital

Interface
1 mm ... 9,999 mm

Sensor Type
Male connector, M12, 5-pin

Operating Temperature
30 C ... +65 C Celsius (oC)

Spectral Range
200 mm ... 10,000 mm

IP Rating
IP65

Ingress Protection
III

Response Time
1 Days

Cable Length
658 nm Nanometer (nm)

Measurement Range
200 mm ... 10,000 mm

Power Rating
IP65

Product Type
Male connector, M12, 5-pin

Input
Multifunctional input (MF)

Output
PNP 100 mA

Function
1 x

Usage
LASER DISTANCE SENSORS

Accuracy
10 mm mm

Resolution
1,000 m ... 1 mm

Voltage
DC 10 V ... 30 V Volt (v)

Rated Voltage
DC 10 V ... 30 V 1) Volt (V)

Weight
200 g Grams (g)

Cable Type
Visible red light

Warranty
1 year

Display Type
Male connector, M12, 5-pin

Frequency
50 Hz / 10 Hz 4) Hertz (HZ)

Rated Current
100 mA Megaampere ( MA)

Material
Plastic (PMMA)

LASER DISTANCE SENSOR: DX50 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
1 Week

About LASER DISTANCE SENSOR: DX50

PRODUCT DISCRIPTION

The Dx50 is a common distance sensor platform, offering multiple performance levels. With measurement ranges of up to 10 m or 20 m on objects or even up to 50 m when measuring on reflector, the Dx50 is suitable for many different applications. Based on a switching, analog or serial interface being available the Dx50 can easily be integrated in any application environment. Also, the intuitive operating concept and a visible red laser allow a fast installation of the sensors. Thanks to the innovative HDDM technol ogy the Dx50 provides excellent reliability, immunity to ambient light and precision when being in use. Offering an extremely good price/performance ratio the Dx50 is the right solution in many cases.

AT A GLANCE

Highest reliability, ambient light immunity and price/performance ratio thanks to HDDM technology.
Measuring ranges of 10 m or 20 m directly on the object or 50 m on the reflector.
Different performance levels depending on the product and laser class.
Various interfaces: Digital, analog or serial.
Display with intuitive and consistent operating concept.
Rugged zinc diecast housing.
Wide operating temperature ranges from 30 C to +65 C

YOUR BENEFITS

Wide measurement ranges up to 10, 20 or 50 m in combination with different interfaces allow an easy and fast integration in any production environment.
Highly reliable and precise measurement helps to increase process quality and stability.
High measurement or switching frequencies enable a fast material flow.
Dx50 product family is based on a common platform, offering multiple performance levels, making it easy to accommodate future changes.
Intuitive setup via display or remote teach reduces installation time and costs.
Temperature range from 30 C to +65 C allows for outdoor use without additional cooling or heating.
Up to 40Klx ambient light immunity allows for use in optically challenging environments
