MZT7 CYLINDER SENSORS

Name: MZT7 CYLINDER SENSORS
Brand: JAY KAY ENTERPRISES
Price: 751.0 INR
Availability: InStock

Price 751.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MZT7 CYLINDER SENSORS Specification

Features
T-slot

Cable Length
29.5 Millimeter (mm)

Application
Monitoring of a rotary gripper using the MZT7

Power Consumption
8 mA Ampere

Sensor Type
MZT7-03VPS-KU0

Housing Material
Plastic

Wireless
No

Ingress Protection
III

Response Time
1 Hours

Signal Type
Digital

IP Rating
IP65

Operating Temperature
30 C ... +80 C Celsius (oC)

Sensitivity
3 mt

Power Rating
IP65

Product Type
MZT7-03VPS-KU0

Input
CYLINDER SENSORS - MZT7-03VPS-KU0

Output
PNP

Function
NO

Usage
Monitoring of a rotary gripper using the MZT7

Accuracy
10 mm

Voltage
10 V DC ... 30 V DC Volt (v)

Rated Voltage
10 V DC ... 30 V DC Volt (V)

Usage & Applications
Monitoring of a rotary gripper using the MZT7

Weight
28 Grams (g)

Warranty
1 year

Cable Type
Cable, 3-wire, stripped, drag chain use, 2 m

Display Type
CYLINDER SENSORS - MZT7-03VPS-KU0

Frequency
1,000 Hertz (HZ)

Material
PUR

Rated Current
100 mA Milliampere (mA)

Conductor
0.14 mm

MZT7 CYLINDER SENSORS Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About MZT7 CYLINDER SENSORS

PRODUCT DESCRIPTION

The SICK MZT7 cylinder sensor with GMR technology reliably detects the piston position in pneumatic drives. The MZT7 can be mounted directly into all cylinders with standard T-slots. SICK also has an extensive range of adapters which enable the MZT7 to be used with other cylinder types. The MZT7 is characterized by its simple mounting principle: Insert the sensor into the slot and rotate the fixing screw a quarter turn to fix it securely to the cylinder.

AT A GLANCE

Can be used in all standard cylinders, linear slides, and grippers using the T-slot and with the help of adapters in round rod, tie-rod, and profile cylinders, and cylinders with a dovetail groove H I J K L M N O P Q R S T
Drop-in mounting from above simplifies handling and assembly
Combined fixing screw (hexagon socket screw and slotted screw)
LED for indicating the output state
Enclosure rating: IP 67

YOUR BENEFITS

A sensor for a wide range of applications: The sensor design fits into all standard T-slots used around the world, regardless of the cylinder profile or make
Simple mounting: Thanks to the retaining ribs on the side, the sensor holds its position even before the screw is tightened, ensuring that it does not fall out
Fast mounting: The sensor is fixed quickly and securely in the slot simply by rotating the fixing screw a quarter turn
The rugged fixing screw holds the sensor in the required position, even when exposed to shock and vibration
It is easy to replace the sensor during servicing without removing the end caps
