Photoelectric Sensor

Name: Photoelectric Sensor
Brand: JAY KAY ENTERPRISES
Price: 1100.0 INR
Availability: InStock

Price 1100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Photoelectric Sensor Specification

Sensor Type
GTB6-P1212

Mounting Type
holes M3

Application
Leading edge detection and presence checking

Housing Material
Plastic, ABS/PC

Measurement Range
5 mm ... 250 mm

Features
Background suppression

Ingress Protection
A 7) B 8) D 9)

Mounting Thread
holes M3

Signal Type
Digital

IP Rating
IP67

Cable Length
2 m Meter (m)

Power Consumption
30 mA Ampere

Response Time
1 Days

Wireless
No

Spectral Range
5 mm ... 250 mm

Operating Temperature
25 C ... +55 C Celsius (oC)

Power Rating
IP67

Product Type
GTB6-P1212

Input
PHOTOELECTRIC SENSORS - GTB6-P1212

Output
PNP

Function
Photoelectric proximity sensor

Usage
Leading edge detection and presence checking

Accuracy
6 mm mm

Resolution
industrial automation

Voltage
10 V DC ... 30 V DC Volt (v)

Weight
60 Grams (g)

Usage & Applications
Leading edge detection and presence checking

Rated Voltage
10 V DC ... 30 V DC Volt (V)

Cable Type
Visible red light

Warranty
1 year

Display Type
PHOTOELECTRIC SENSORS - GTB6-P1212

Frequency
1,000 Hertz (HZ)

Conductor
0.14 mm

Material
Plastic, PMMA

Rated Current
30 mA Milliampere (mA)

Photoelectric Sensor Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About Photoelectric Sensor

PRODUCT DESCRIPTION

The photoelectric sensors in the G6 product family with their miniature housings will impress you across the board with both their standard mounting configuration of 1-inch spaced holes and also their functional characteristics. The variants with a stainless steel 1.4404 (316L) housing are especially resistant to chemicals and cleaning agents in washdown applications. With Pinpoint LED and laser technology, metal inserts for mounting, large and bright indicator LEDs, user-friendly adjustment screws, IP67 and IP69K enclosure ratings, as well as the very latest ASIC technology from SICK, the G6 series far exceeds the current standard.

AT A GLANCE

Pinpoint LED and class 1 laser variants.
SICK ASIC, the result of decades of experience with photoelectric sensors.
Photoelectric proximity sensors with background suppression, energetic. photoelectric proximity sensors, and through-beam photoelectric sensors.
ABS plastic housing and V4A stainless-steel 1.4404 (316L) housing.
Enclosure ratings IP67 and IP69K

YOUR BENEFITS

Pinpoint LEDs (with visible red light and infrared light) or variants with a laser light spot enable objects to be detected reliably and are therefore suitable for a broad range of applications.
Superior optical performance and robustness thanks to the ASIC from SICK.
Quick and easy mounting and high durability thanks to the metal inserts with M3 thread.
Easy installation and adjustment with user friendly potentiometer and highly visible indicator LEDs.
Variants with a stainless-steel housing and IP69K enclosure rating ensure a long sensor service life in demanding washdown ap plications

FIELDS OF APPLICATION

Industries with high cleaning requirements (e.g. food and beverage).
Harsh environments requiring tough metal housing. e.g. due to mechanical impacts.
Applications with high aesthetic standards
