PHOTOELECTRIC SENSORS

Price 4998.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Number

PHOTOELECTRIC SENSORS Specification

Response Time
1 Days

IP Rating
IP67

Cable Length
300 mm Millimeter (mm)

Application
Monitoring access barriers

Operating Temperature
30 C ... +60 C Celsius (oC)

Features
Photoelectric proximity sensor

Sensor Type
GTB10-F7431S14

Spectral Range
20 mm ... 1,600 mm

Signal Type
Digital

Mounting Type
hole, 4.2 mm

Housing Material
Plastic, ABS/PMMA

Wireless
No

Power Consumption
20 mA Ampere

Mounting Thread
hole, 4.2 mm

Ingress Protection
A 6) B 7) C 8) D 9)

Power Rating
IP67

Product Type
GTB10-F7431S14

Input
PHOTOELECTRIC SENSORS

Output
PNP

Function
Complementary

Usage
Monitoring access barriers

Accuracy
8 mm mm

Voltage
10 V DC ... 30 V DC Volt (v)

Rated Voltage
10 V DC ... 30 V DC Volt (V)

Weight
85 Grams (g)

Usage & Applications
Monitoring access barriers

Cable Type
Cable with M12 male connector, 4-pin, 300 mm

Warranty
1 year

Display Type
PHOTOELECTRIC SENSORS

Frequency
200 Hz Hertz (HZ)

Rated Current
20 mA Milliampere (mA)

Material
Plastic, PVC

Conductor
4-pin

PHOTOELECTRIC SENSORS Trade Information

Minimum Order Quantity
1 Number

Delivery Time
1 Week

About PHOTOELECTRIC SENSORS

PRODUCT DESCRIPTION

The G10 product family is characterized by optimum detection performance wherever space is at a premium. It supports numerous different options for optics, electronics, principles of operation, power supplies, and switching outputs. Combined with an extensive range of accessories, these sensors are able to support a wide variety of applications. The patented Q-Lock assembly system for the G10 reduces the time required to install and align the sensor with an assembly rod to just a few seconds, making this the ide al product for logistics applications. Summary: The G10 product family provides quick and flexible sensor installation, ensures error-free operation, and keeps costs under control.

AT A GLANCE

Long sensing ranges: 1,200 mm with background suppression; 15 m on PL80A reflector.
Pinpoint LED with bright and precise light spot.
Small housing design.
10 30 VDC or 24 240 VAC/VDC power supply with PNP/NPN or relay output.
Rugged sensor housing with metal-reinforced holes for assembly.
Q-Lock assembly system for mounting the sensor within a few seconds.

YOUR BENEFITS

Long sensing ranges for maximum operating reserves.
Efficient installation: The G10 and the Q-Lock assembly system save valuable hours when mounting and commissioning multiple sensors.
A single sensor family for all industrial and commercial fields of application.
Universal DC or AC/DC power supply for even greater application flexibility.
Highly reliable and durable despite optical interference or mechanical loads.
Wide range of accessories simplifies sensor integration: aids for assembly, connecting cables, and reflectors.
