The G10 product family is characterized by optimum detection performance wherever space is at a premium. It supports numerous different options for optics, electronics, principles of operation, power supplies, and switching outputs. Combined with an extensive range of accessories, these sensors are able to support a wide variety of applications. The patented Q-Lock assembly system for the G10 reduces the time required to install and align the sensor with an assembly rod to just a few seconds, making this the ide al product for logistics applications. Summary: The G10 product family provides quick and flexible sensor installation, ensures error-free operation, and keeps costs under control.

•  Long sensing ranges: 1,200 mm with background suppression; 15 m on PL80A reflector.
• Pinpoint LED with bright and precise light spot.
• Small housing design.
• 10 30 VDC or 24 240 VAC/VDC power supply with PNP/NPN or relay output.
• Rugged sensor housing with metal-reinforced holes for assembly.
• Q-Lock assembly system for mounting the sensor within a few seconds.

YOUR BENEFITS

•  Long sensing ranges for maximum operating reserves.
• Efficient installation: The G10 and the Q-Lock assembly system save valuable hours when mounting and commissioning multiple sensors.
• A single sensor family for all industrial and commercial fields of application.
• Universal DC or AC/DC power supply for even greater application flexibility.
• Highly reliable and durable despite optical interference or mechanical loads.
• Wide range of accessories simplifies sensor integration: aids for assembly, connecting cables, and reflectors.

FIELDS OF APPLICATON

•  Logistics: Storage & Conveyor, especially pallet detection.
• Machine builders (e.g. packaging, handling, wood processing, paper).
• Automotive.
• Automated car park systems.
• Doors and gates.
• Distribution.

 ORDERING INFORMATION

•  Other models and accessories www.sick.com/G10.
• Functional principle: Photoelectric proximity sensor.
• Functional principal detail: Background suppression.
• Light source: LED.
• Voltage type: DC.
• Switching mode: Light/dark switching.
• Type of light: Infrared light.
