PHOTOELECTRIC SENSORS

Price 3600.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

PHOTOELECTRIC SENSORS Specification

Signal Type
Digital

Housing Material
Metal, Nickel-plated brass

Power Consumption
30 mA Ampere

Measurement Range
3 mm ... 100 mm

Cable Length
63.6 mm Millimeter (mm)

Response Time
1 Days

Wireless
No, Yes

Sensor Type
PHOTOELECTRIC SENSORS - VTF18-4N1212

IP Rating
IP67

Spectral Range
3 mm ... 100 mm

Features
Focused optics

Ingress Protection
A 8) B 9) C 10) D 11)

Application
An application can look very different in different industries

Operating Temperature
25 C ... +70 C Celsius (oC)

Power Rating
IP67

Product Type
VTF18-4N1212

Input
PHOTOELECTRIC SENSORS - VTF18-4N1212

Output
NPN

Function
Background suppression

Usage
An application can look very different in different industries

Accuracy
3 mm mm

Resolution
solutions in industrial automation

Voltage
10 V DC ... 30 V DC Volt (v)

Weight
120 Grams (g)

Usage & Applications
An application can look very different in different industries

Rated Voltage
10 V DC ... 30 V DC Volt (V)

Warranty
1 year

Cable Type
Cable, 4-wire, 2 m

Display Type
PHOTOELECTRIC SENSORS - VTF18-4N1212

Conductor
0.14 mm

Material
Plastic, PMMA

Rated Current
30 mA Milliampere (mA)

Frequency
250 Hz Hertz (HZ)

PHOTOELECTRIC SENSORS Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About PHOTOELECTRIC SENSORS

PRODUCT DESCRIPTION

The V18 Laser family of photoelectric sensors offers modern laser technology with a small, highly visible light spot that detects small parts and offers precise sensing. These laser class 1 sensors provide long sensing distances and short response times. Yellow and green indicator LEDs ensure easy mounting, commissioning, adjustment and maintenance. Sensitivity can be set in several ways - either manually via a teach-in pushbutton or electronically using control input C.

AT A GLANCE

Laser emitter LED enclosed in a cylindrical M18 housing.
Laser class 1.
Fast response time H I J K L M N O P Q R S T.
Straight or right-angle housing.
Durable metal housing.
IP 67.
Small visible light spot to detect small objects.

YOUR BENEFITS

Laser sensor in cylindrical M18 housing lowers installation costs.
Time-saving installation and commissioning due to clearly visible light spot.
Laser class 1 does not require any enhanced safety measures or labeling, which lowers installation costs.
Quick response time ensures reliable object detection at high speeds, which increases the machine's throughput.
