Send InquiryACS/ACM36 ABSOLUTE ENCODERS
Price 3000.0 INR/ Piece
MOQ : 1 Piece
ACS/ACM36 ABSOLUTE ENCODERS Specification
- Spectral Range
- 336
- Response Time
- 1 Days
- Sensor Type
- ACM36-K1K0-K01
- Operating Temperature
- 30 C ... +80 C Celsius (oC)
- Signal Type
- Digital
- Housing Material
- AlMgSi
- Wireless
- No
- IP Rating
- IP65
- Cable Length
- 1.5 Meter (m)
- Power Consumption
- < 80 mA Ampere
- Measurement Range
- 336
- Ingress Protection
- yes
- Product Type
- ACM36-K1K0-K01
- Power Rating
- IP65
- Input
- ABSOLUTE ENCODERS
- Output
- 4 ... 20 mA
- Accuracy
- 0.2 % %
- Resolution
- 0.11 ... 1.93 1)
- Voltage
- 19 ... 33 V DC Volt (v)
- Weight
- 0.1 kg Kilograms (kg)
- Rated Voltage
- 19 ... 33 V DC Volt (V)
- Warranty
- 1 year
- Cable Type
- Cable, radial, 1.5 m
- Display Type
- ABSOLUTE ENCODERS
- Rated Current
- 80 Milliampere (mA)
- Material
- PVC
ACS/ACM36 ABSOLUTE ENCODERS Trade Information
- Minimum Order Quantity
- 1 Piece
- Delivery Time
- 1 Week
About ACS/ACM36 ABSOLUTE ENCODERS
Product description
The ACS36 (singleturn) and ACM36 (multiturn) encoder families have an analog interface with a maximum resolution of up to 3723 steps (for singleturn and multiturn). Using the teach-in function on the membrane keyboard, the measuring range can be intuitively programmed directly on the device in just a few clicks. A current signal of 4-20 mA or a voltage signal of 0-10 V is output depending on the device version.
At a glance
- Compact 36 mm absolute encoder with up to 3,723 steps (for singleturn and multiturn)
- Servo flange
- Radial cable connection
- Analog interface 4 to 20 mA or 0 to 10 V
- Programming via keypad on the encoder
- IP65 protection class
- Operating temperature: 30 C to +80 C
Your benefits
- Intuitive configuration of the measuring range directly on the device using membrane keyboard (teach-in function) saves time and requires no special expertise.
- The compact size (36-mm format) allows the encoder to be used in confined spaces and thus provides greater freedom for development and machine design.
- The analog interfaces (current/voltage) offer a low-cost solution for detecting the position and path, and thereby help to reduce overall system costs
Fields of application
- Measurement of the absolute position in a variety of industries, machines and equipment, for example:
- Automatically guided vehicle systems (AGS)
- Industrial trucks
- Commercial vehicles
- Packaging machinery
- Logistics applications
- Mechanical engineering
- Medical technology
Ordering information
- Mechanical design: Solid shaft, Servo flange
- Communication interface:
- Shaft diameter: 6 mm
- Connection type: cable, radial, 1.5 m
