Send InquirySAFETY SINGLE-BEAM SENSORS
Price 13000.0 INR/ Piece
MOQ : 1 Piece
SAFETY SINGLE-BEAM SENSORS Specification
- Signal Type
- Digital
- Measurement Range
- 16 m
- Response Time
- 1 Week
- Interface
- LED
- Features
- Type 4 (IEC 61496-1) 1)
- Housing Material
- Plastic
- Sensor Type
- L41E-21KA1A
- Application
- Monitoring of safety doors
- Mounting Type
- Type 4 (IEC 61496-1) 1)
- Power Consumption
- 30 mA Ampere
- Wireless
- No
- IP Rating
- IP67 (EN 60529)
- Ingress Protection
- III (IEC 61140)
- Spectral Range
- 16 m
- Cable Length
- 2 Meter (m)
- Operating Temperature
- 40 C ... +55 C Celsius (oC)
- Power Rating
- IP67 (EN 60529)
- Product Type
- L41E-21KA1A
- Input
- SAFETY SINGLE-BEAM SENSORS
- Usage
- Monitoring of safety doors
- Accuracy
- 30 mm
- Voltage
- 24 V DC Volt (v)
- Rated Voltage
- 24 V DC Volt (V)
- Weight
- 30 Grams (g)
- Usage & Applications
- Monitoring of safety doors
- Warranty
- 1 year
- Display Type
- SAFETY SINGLE-BEAM SENSORS
- Frequency
- 1000 Hertz (HZ)
- Material
- Glass
- Rated Current
- 70 Milliampere (mA)
SAFETY SINGLE-BEAM SENSORS Trade Information
- Minimum Order Quantity
- 1 Piece
- Delivery Time
- 1 Week
About SAFETY SINGLE-BEAM SENSORS
PRODUCT DESCRIPTION
The L41 single-beam photoelectric safety switch consists of a sender and a receiver. The test input of the sender supports direct functional testing. Performance level PL e to EN ISO 13849 or Type 4 to IEC 61496 can be achieved in conjunction with an evaluation unit. Suitable evaluation units include Flexi Classic or Flexi Soft. Color LEDs provide local information about the operational status. The required sensing range can be selected from various device versions. All devices are suitable for applications in challenging ambient conditions and enable even complex protection tasks to be accomplished by using deflector mirrors.AT A GLANCE
- Type 4 (IEC 61496), SIL3 (IEC 61508), PL e (EN ISO 13849), only in conjunction with suitable testing device, e.g., Flexi Classic or Flexi Soft.
- Small M18 sensors with ranges up to 10 m.
- Compact M30 sensors with ranges up to 60 m.
- Enclosure rating IP 67.
- Temperature range from 40 C ... +55 C.
- Radial optics (90 deflector mirror).
YOUR BENEFITS
- Easy integration due to small, compact versions with maximum range.
- Directly connect to a safety controller reducing costs.
- Flexible device integration makes it possible to set up individual access protections.
- Well suited to withstand extreme ambient conditions such as heat, cold or moisture.
FIELDS OF APPLICATION
- Access or area protection on machining centers and robot cells.
- Monitoring of doors and service openings on machines.
- Optical safety edges for protecting automated guided vehicles.
